MOBILE GENERATORS
BUILT TO PERFORM IN ANY ENVIRONMENT
AIRMAN®’S 220 kVA prime power generator provides 608 amps at three-phase 208 volts and 491 amps in single-phase 240 volts with 23.5 hours of runtime, fuel tank at full load, and external tank connections for extended runtimes and 110% spill containment. The SDG220 delivers the industry’s leading automatic voltage regulation (0.5%), best-in-class motor starting capability, all in a rugged weatherproof sound attenuated encloser.
INSTRUCTION & PART MANUALS
OPTIONAL ACCESSORIES
Engine Coolant Heater Kit
Single Cam LoKstm Kit
Battery Blanket
600 V
Battery Charger
Lockable Battery Disconnect
Fuel Filter Heater
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
ENGINE MODEL | John Deere 6068 |
OUTPUT @ RATED SPD (1,800 RPM) | 295 HP |
PRIME POWER | 220 kVA / 176 kW |
STANDBY POWER | 242 kVA / 194 kW |
VOLTAGE 1 PHASE (SWITCHABLE) | 120V / 127V / 139V 240V / 254V / 277V |
VOLTAGE 3 PHASE (SWITCHABLE) | 208V / 220V / 240V 416V / 440V/ 480V |
AMPERAGE 1 PHASE 120V | 491 A x 2 |
AMPERAGE 1 PHASE 240V | 491 A |
AMPERAGE 3 PHASE 208V | 608 A |
AMPERAGE 3 PHASE 240V | 529 A |
AMERPAGE 3 PHASE 480V | 264 A |
RUN TIME @ FULL LOAD | 23.5 hrs |
INTEGRAL FUEL TANK CAPACITY | 285 gal |
EPA EMISSION LEVEL | Tier 4 Final |
OPERATING WEIGHT | 9,656 lbs |
DRY WEIGHT | 7,452 lbs |
GVWR | 11,021 lbs |
TRAILER WEIGHT | 1,365 lbs |
DIMENSIONS (W/O TRAILER) | 137.8″ L x 51.2″ W x 87.4″ H |
DIMENSIONS (W TRAILER) | 219″ L x 83.75″ W x 103.4″ H |
Features and specifications may change without notice.
See servicing dealer for complete warranty details.
Consult ANA for all current information.
