MOBILE GENERATORS
BUILT TO PERFORM IN ANY ENVIRONMENT
AIRMAN®’s 65kVA prime power generator provides 167 amps at three-phase 208V and 152 amps in single-phase 240V with 28.5 hour runtime at full load. Our containment system provides 110% containment for fuel, oil and coolant.
SDG65 GENERATOR SPECIFICATIONS
AIRMAN®'s SDG65 generator provides 65 kVA of prime power.
AIRMAN GENERATORS PRODUCT LINEUP
ANA's current lineup of AIRMAN® mobile generators. Find out about each model and its features and benefits.
AIRMAN GENERATORS PRODUCT LINEUP
ANA's current lineup of AIRMAN mobile generators. Find out about each model and its features and benefits.
AIRMAN GENERATOR SERVICE POINTS
Identifying service points inside an AIRMAN® generator for proper preventative maintenance.
SETTING VOLTAGE ON A GENERATOR
How to properly set voltage on your AIRMAN® generator
HOOK UPS: LUGS VS PLUGS
How to complete a proper wire-up procedure on the current line of AIRMAN® Generators.
INSTRUCTION & PARTS MANUALS
OPTIONAL ACCESSORIES
Engine Coolant Heater Kit
Single Cam LoKstm Kit
Battery Blanket
Engine Block Heater
4-Position Selector Switch
Battery Charger
Lockable Battery Disconnect
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
ENGINE MODEL | Isuzu 4JJ1X |
OUTPUT @ RATED SPD (1,800 RPM) | 86.5 Hp |
PRIME POWER | 65 kVA / 51 kW |
STANDBY POWER | 69.3 kVA / 55.4 kW |
VOLTAGE 1 PHASE (SWITCHABLE) | 120V / 240V 277V |
VOLTAGE 1 PHASE (SWITCHABLE) | 208V / 240V 416V / 480V |
AMPERAGE 1 PHASE 120V | 152 A x 2 |
AMPERAGE 1 PHASE 240V | 152 A |
AMPERAGE 3 PHASE 208V | 167 A |
AMPERAGE 3 PHASE 240V | 152 A |
AMERPAGE 3 PHASE 480V | 76 A |
RUN TIME @ FULL LOAD | 28.5 hrs |
INTEGRAL FUEL TANK CAPACITY | 111 gal |
EPA EMISSION LEVEL | Tier 4 Final |
OPERATING WEIGHT | 4,189 lbs |
DRY WEIGHT | 3,307 lbs |
GVWR | 5,414 lbs |
TRAILER WEIGHT | 1,074 lbs |
DIMENSIONS (W/O TRAILER) | 97″ L x 39″ W x 67″ H |
DIMENSIONS (W TRAILER) | 160″ L x 74″ W x 84.25″ H |
Features and specifications may change without notice.
See servicing dealer for complete warranty details.
Consult ANA for all current information.
