Product Feature Highlights
BUILT TO PERFORM IN ANY ENVIRONMENT
Reliable, quiet, and perfectly sized for your needs, the AIRMAN® PDS100 series portable air compressor delivers top quality at the greatest value. Designed for easy maintenance and equipped with advanced ECO-Mode fuel economy, this portable air compressor ensures maximum efficiency while keeping your job moving forward and costs down. Whether you need dependable power for construction, industrial, or rental applications, trust AIRMAN® to deliver performance you can rely on.
PDS100 COMPRESSOR SPECIFICATIONS
Demonstration video of the AIRMAN® PDS100S-6E1 air compressor and its features and benefits.
ADJUSTING AIR PRESSURE
How to adjust air pressure on the AIRMAN® line of Air Compressors
STARTUP PROCEDURE FOR COMPRESSORS
How to perform a proper startup procedure for the AIRMAN® PDS185S-6E1 air compressor.
SHUTDOWN PROCEDURE FOR COMPRESSORS
How to properly shutdown your AIRMAN® air compressor.
Hose Reel Kit
Battery Charger
TECHNICAL SPECIFICATIONS
ENGINE MODEL | Kubota D1005-E48 |
HORSEPOWER | 24.8 HP |
FREE AIR DELIVERY | 100 cfm |
WORKING PRESSURE | 100 psig |
MAX. WORKING PRESSURE | 120 psig |
AIR RECEIVER TANK CAPACITY | 5.3 gal |
AIR OUTLETS | 3/4" x 2 |
FUEL CAPACITY | 10.6 gal |
SOUND LEVEL | 68 dBA |
OPERATING WEIGHT | 1,625 lbs |
DRY WEIGHT | 1,179 lbs |
WEIGHT W/ TOWING FRAME | 1,515 lbs |
DIMENSIONS (W/O TRAILER) | 64″ L x 39″ W x 37″ H |
DIMENSIONS (W TRAILER) | 64″ L x 56″ W x 65″ H |
