MOBILE GENERATORS
BUILT TO PERFORM IN ANY ENVIRONMENT
AIRMAN®’s compact 12.5kVA/10kW prime power generator provides 30 amps at three-phase 208V and 40 amps in single-phase 240V with 27-hour runtime at full load. Configured with the industry’s best automatic voltage regulation (+/-0.5%), providing the widest range of voltage selection, AIRMAN® generators out-perform in any environment.
SDG13 GENERATOR SPECIFICATIONS
AIRMAN®'s SDG13 generator provides single and three phase power in a compact package.
AIRMAN GENERATORS PRODUCT LINEUP
ANA's current lineup of AIRMAN® mobile generators. Find out about each model and its features and benefits.
AIRMAN GENERATOR SERVICE POINTS
Identifying service points inside an AIRMAN® generator for proper preventative maintenance.
SETTING VOLTAGE ON A GENERATOR
How to properly set voltage on your AIRMAN® generator
HOOK UPS: LUGS VS PLUGS
How to complete a proper wire-up procedure on the current line of AIRMAN® Generators.
MANUALS
OPTIONAL ACCESSORIES
Auto Start
Battery Charger
Fuel Filter Heater
Battery Blanket
Lockable Battery Disconnect
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
ENGINE MODEL | Kubota D1503 |
OUTPUT @ RATED SPD (1,800 RPM) | 18.4 HP |
PRIME POWER | 12.5 kVA / 10 kW |
STANDBY POWER | 13.8 kVA / 11 kW |
VOLTAGE 1 PHASE (SWITCHABLE) | 120V / 240V |
VOLTAGE 3 PHASE (SWITCHABLE) | 208V / 240V |
AMPERAGE 1 PHASE 120V | 40 A x 2 |
AMPERAGE 1 PHASE 240V | 40 A |
AMPERAGE 3 PHASE 208V | 30 A |
AMPERAGE 3 PHASE 240V | 30 A |
RUN TIME @ FULL LOAD | 27.7 hrs |
INTEGRAL FUEL TANK CAPACITY | 26.4 gal |
EPA EMISSION LEVEL | Tier 4 Final |
OPERATING WEIGHT | 15,00 lbs |
DRY WEIGHT | 1,290 lbs |
GVWR | 1,995 lbs |
TRAILER WEIGHT | 494 lbs |
DIMENSIONS (W/O TRAILER) | 55″ L x 26″ W x 46″ H |
DIMENSIONS (W TRAILER) | 120″ L x 60″ W x 60″ H |
Features and specifications may change without notice.
See servicing dealer for complete warranty details.
Consult ANA for all current information.
