MOBILE GENERATORS
BUILT TO PERFORM IN ANY ENVIRONMENT
AIRMAN®’s 150 kVA prime power generator provides 394 amps at three-phase 208 volt, 180 amps at 480 volt and over 360 amps in single phase 240 volt. You get over 24-hour runtime at full load, and at 66 dBA it is the quietest in the industry.
SDG150 GENERATOR SPECIFICATIONS
AIRMAN®'s SDG150 generator provides 150 kVA of prime power.
AIRMAN GENERATORS PRODUCT LINEUP
ANA's current lineup of AIRMAN® mobile generators. Find out about each model and its features and benefits.
AIRMAN GENERATOR SERVICE POINTS
Identifying service points inside an AIRMAN® generator for proper preventative maintenance.
SETTING VOLTAGE ON A GENERATOR
How to properly set voltage on your AIRMAN® generator
HOOK UPS: LUGS VS PLUGS
How to complete a proper wire-up procedure on the current line of AIRMAN® Generators.
INSTRUCTION & PARTS MANUAL
OPTIONAL ACCESSORIES
Int/Ext Engine Coolant Heater Kits
Dual Cam LoKstm Kit
Battery Blanket
Engine Block Heater
4-Position Selector Switch
Battery Charger
Thermosyphon Heater
Lockable Battery Disconnect
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
ENGINE MODEL | John Deere 6068 HFG 05 |
OUTPUT @ RATED SPD (1,800 RPM) | 235 Hp |
PRIME POWER | 150 kVA / 120 kW |
STANDBY POWER | 165 kVA / 132 kW |
VOLTAGE 1 PHASE (SWITCHABLE) | 120V / 240V 277V |
VOLTAGE 1 PHASE (SWITCHABLE) | 208V / 240V 416V / 480V |
AMPERAGE 1 PHASE 120V | 363 A x 2 |
AMPERAGE 1 PHASE 240V | 363 A |
AMPERAGE 3 PHASE 208V | 394 A |
AMPERAGE 3 PHASE 240V | 361 A |
AMERPAGE 3 PHASE 480V | 180 A |
RUN TIME @ FULL LOAD | 24 hrs |
INTEGRAL FUEL TANK CAPACITY | 204 gal |
EPA EMISSION LEVEL | Tier 4 Final |
OPERATING WEIGHT | 8,488 lbs |
DRY WEIGHT | 6,878 lbs |
GVWR | 9,838 lbs |
TRAILER WEIGHT | 1,350 lbs |
DIMENSIONS (W/O TRAILER) | 113.4″ L x 51.2″ W x 72.8″ H |
DIMENSIONS (W TRAILER) | 196″ L x 79″ W x 85″ H |
Features and specifications may change without notice.
See servicing dealer for complete warranty details.
Consult ANA for all current information.
