MOBILE GENERATORS
BUILT TO PERFORM IN ANY ENVIRONMENT
AIRMAN®’s 400kVA prime power generator provides 1,048 amps at three-phase 208V and 50 amps x 3 in single-phase 240V with 21.3 hour runtime at full load. Powered by an Isuzu 6WG engine with electronic fuel priming and air bleed for minimal downtime. Delta Demand Excitation delivers the industry’s best motor starting capability and automatically adjusts to varying loads.
SDG400 GENERATOR SPECIFICATIONS
AIRMAN®'s SDG400 generator provides 400 kVA of prime power.
WHEN YOU NEED BIG POWER
Looking to boost your business's power capabilities? Our generators are equipped with integrated fuel tanks, Automatic Voltage Regulation, and more to deliver reliable performance and maximum efficiency.
AIRMAN GENERATORS PRODUCT LINEUP
ANA's current lineup of AIRMAN® mobile generators. Find out about each model and its features and benefits.
AIRMAN GENERATOR SERVICE POINTS
Identifying service points inside an AIRMAN® generator for proper preventative maintenance.
SETTING VOLTAGE ON A GENERATOR
How to properly set voltage on your AIRMAN® generator
HOOK UPS: LUGS VS PLUGS
How to complete a proper wire-up procedure on the current line of AIRMAN® Generators.
INSTRUCTION & PART MANUALS
OPTIONAL ACCESSORIES
Engine Coolant Heater Kit
Triple Cam LoKstm Kit
Battery Blanket
Engine Block Heater
Battery Charger
Thermosyphon Heater
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
ENGINE MODEL | Isuzu 6WG1X |
OUTPUT @ RATED SPD (1,800 RPM) | 457.7 Hp |
PRIME POWER | 400 kVA / 320 kW |
STANDBY POWER | 420 kVA / 336 kW |
VOLTAGE 1 PHASE (SWITCHABLE) | 120V / 127V / 139V 240V / 254V / 277V |
VOLTAGE 1 PHASE (SWITCHABLE) | 208V / 220V / 240V 416V / 440V/ 480V |
AMPERAGE 1 PHASE 120V | 893 A x 2 |
AMPERAGE 1 PHASE 240V | 893 A |
AMPERAGE 3 PHASE 208V | 1,048 A |
AMPERAGE 3 PHASE 240V | 962 A |
AMERPAGE 3 PHASE 480V | 481 A |
RUN TIME @ FULL LOAD | 21.3 hrs |
INTEGRAL FUEL TANK CAPACITY | 491 gal |
EPA EMISSION LEVEL | Tier 4 Final |
OPERATING WEIGHT | 17,042 lbs |
DRY WEIGHT | 13,206 lbs |
GVWR | 19,602 lbs |
TRAILER WEIGHT | 2,650 lbs |
DIMENSIONS (W/O TRAILER) | 177″ L x 59″ W x 107.5″ H |
DIMENSIONS (W TRAILER) | 270″ L x 92″ W x 127″ H |
Features and specifications may change without notice.
See servicing dealer for complete warranty details.
Consult ANA for all current information.
