MOBILE GENERATORS
BUILT TO PERFORM IN ANY ENVIRONMENT
AIRMAN®’s SDG45S-8E2 provides 28.75 hours of runtime at full 36kW load, with safety features that include a curbside electrical panel, automatic shutdowns, and an external drain for simple preventive maintenance. Delta Demand Excitation delivers the industry’s best motor starting capability, adjusting automatically as loads vary.
SDG45 GENERATOR SPECIFICATIONS
AIRMAN®'s SDG45 generator provides 45 kVA of prime power.
AIRMAN GENERATORS PRODUCT LINEUP
ANA's current lineup of AIRMAN® mobile generators. Find out about each model and its features and benefits.
AIRMAN GENERATOR SERVICE POINTS
Identifying service points inside an AIRMAN® generator for proper preventative maintenance.
SETTING VOLTAGE ON A GENERATOR
How to properly set voltage on your AIRMAN® generator
HOOK UPS: LUGS VS PLUGS
How to complete a proper wire-up procedure on the current line of AIRMAN® Generators.
INSTRUCTION & PART MANUALS
OPTIONAL ACCESSORIES
Engine Coolant Heater Kit
Single Cam LoKstm Kit
Battery Blanket
Engine Block Heater
4-Position Selector Switch
Battery Charger
Lockable Battery Disconnect
Fuel Filter Heater
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
ENGINE MODEL | Isuzu 4LE2X |
OUTPUT @ RATED SPD (1,800 RPM) | 57.7 HP |
PRIME POWER | 45 kVA / 36 kW |
STANDBY POWER | 48.5 kVA / 38.8 kW |
VOLTAGE 1 PHASE (SWITCHABLE) | 120V / 240V 277V |
VOLTAGE 3 PHASE (SWITCHABLE) | 208V / 240V 416V / 480V |
AMPERAGE 1 PHASE 120V | 60 A x 2 |
AMPERAGE 1 PHASE 240V | 60 A |
AMPERAGE 3 PHASE 208V | 119 A |
AMPERAGE 3 PHASE 240V | 108 A |
AMERPAGE 3 PHASE 480V | 54 A |
RUN TIME @ FULL LOAD | 28.75 hrs |
INTEGRAL FUEL TANK CAPACITY | 80.5 gal |
EPA EMISSION LEVEL | Tier 4 Final |
OPERATING WEIGHT | 3,337 lbs |
DRY WEIGHT | 2,954 lbs |
GVWR | 4,519 lbs |
TRAILER WEIGHT | 1,182 lbs |
DIMENSIONS (W/O TRAILER) | 74.8″ L x 38.2″ W x 61.4″ H |
DIMENSIONS (W TRAILER) | 144″ L x 70″ W x 73″ H |
Features and specifications may change without notice.
See servicing dealer for complete warranty details.
Consult ANA for all current information.
