AIRMAN Three Phase Generator
Product Feature Highlights
THREE PHASE GENERATOR: BUILT TO PERFORM IN ANY ENVIRONMENT
AIRMAN’s SDG40S three phase generator delivers 36 kVA of prime power with 95 amps at three-phase 208V and 108 amps in single-phase 240V, ensuring reliable performance for demanding applications. With an impressive runtime of over 36 hours at full load, this generator is built for endurance. Its generator ends feature a series star wire high-wye configuration, offering best-in-class motor starting capability. The AIRMAN SDG40S three phase generator combines efficiency and power for versatile use in any environment.
6 Questions to Properly Size a Generator
SDG40 GENERATOR SPECIFICATIONS
Demonstration video of the AIRMAN® SDG40S-8E1 generator and its features and benefits.
AIRMAN GENERATORS PRODUCT LINEUP
ANA's current lineup of AIRMAN® mobile generators. Find out about each model and its features and benefits.
AIRMAN GENERATOR SERVICE POINTS
Identifying service points inside an AIRMAN® generator for proper preventative maintenance.
SETTING VOLTAGE ON A GENERATOR
How to properly set voltage on your AIRMAN® generator
HOOK UPS: LUGS VS PLUGS
How to complete a proper wire-up procedure on the current line of AIRMAN® Generators.
Cold Weather/Winterizing Package
- Battery Blanket
- CCV Heater
- Fuel Filter Heater
- Engine Block Heater - Freeze Plug
- Lower Radiator Hose Heater
Installation & Mounting Options
- Skid-Mounted Option
- Trailer-Mounted Option
- Single Axle Trailer - Surge or Electric Brakes
- Dual Axle Trailer - Surge or Electric Brakes
- 2" Ball Hitch or 2-5/16" Ball Hitch
- 3" Pintle Hitch
Additional Accessories
- Smart Load Resistive Load Bank - 12kW
- Single Cam LoK™ kit
- Battery Charger - 12V/6A
- Lockable Battery Disconnect
- Installation of ZTR Telematics Module
TECHNICAL SPECIFICATIONS
|
ENGINE MODEL
|
Kubota V2403
|
|
OUTPUT @ RATED SPD (1,800 RPM)
|
44.9 HP
|
|
PRIME POWER
|
36 kVA / 28.6 kW
|
|
STANDBY POWER
|
37.8 kVA / 30.2 kW
|
|
VOLTAGE 1 PHASE (SWITCHABLE)
|
120V /240V
277V
|
|
VOLTAGE 3 PHASE (SWITCHABLE)
|
208V / 240V
416V / 480V
|
|
AMPERAGE 1 PHASE 120V
|
108 A x 2
|
|
AMPERAGE 1 PHASE 240V
|
108 A
|
|
AMPERAGE 3 PHASE 208V
|
95 A
|
|
AMPERAGE 3 PHASE 240V
|
86 A
|
|
AMERPAGE 3 PHASE 480V
|
43 A
|
|
RUN TIME @ FULL LOAD
|
37 hrs
|
|
INTEGRAL FUEL TANK CAPACITY
|
84.5 gal
|
|
EPA EMISSION LEVEL
|
Tier 4 Final
|
|
OPERATING WEIGHT
|
3,065 lbs
|
|
DRY WEIGHT
|
2,426 lbs
|
|
GVWR
|
4,247 lbs
|
|
TRAILER WEIGHT
|
1,182 lbs
|
|
DIMENSIONS (W/O TRAILER)
|
67″ L x 31″ W x 55″ H
|
|
DIMENSIONS (W TRAILER)
|
144″ L x 70″ W x 73″ H
|
